Question Can you cut 45 degree angles with a router bit?
Report Post Report This Post!

Hi from AZ. My husband, Paul, and I are attempting to build a bar. The project design said it is for novices, but I am not so sure. Can you cut 45 degree angles with a router bit? If so, what bit? We have to cut 45 degree angles into both sides of a 2 x 6. They are only 1/4 inch deep.

jchutch75 is offline
Sponsored Advertisement - Register now to remove this advertisement.
** Please be sure to read our Disclaimer at the bottom of the page. **

Advertisement

These advertisements are only displayed to guests, register now for your FREE account on the worlds largest router and woodworking community!
Old 11-13-2011, 12:39 PM   #2 (permalink)
Registered User

Join Date: Nov 2009
Country: United States
First Name: James
Posts: 2,304
jlord is on a distinguished road

Default
Report Post Report This Post!

Welcome.
You just need to bevel an edge at 45º? That's not a problem. You can go to a Home Depot or Lowe's or any place that sells router bits & pick up a 45º chamfer bit that has a bearing mounted on it. You can get this bit with a 1/4" or 1/2" shank. Make sure your router can handle a 1/2" if you buy the larger shank. All routers will take the 1/4". Here's a link to what type of bit you need. Use a piece of scrap to do a test cut then when you like the sample then you can proceed to your bar pieces. Can be done in one pass.

Rockler 45 Degree Chamfer Router Bits - Rockler Woodworking Tools
__________________
James
Whittier, CA.

Have a nice & safe day!

Last edited by jlord; 11-13-2011 at 12:42 PM.
jlord is offline
Old 11-13-2011, 02:42 PM   #3 (permalink)
Forum Contributor

xplorx4's Avatar

Join Date: Dec 2008
Country: United States
First Name: Jerry
Posts: 10,646
xplorx4 will become famous soon enough

Default
Report Post Report This Post!

Greetings and welcome to the router forums, we are glad to have you join us.

The chamfer bit will do the trick. The bit will come with a guide bearing on top so it can be used in or out of a router table. Just use a piece if scrap to set the depth to the 1/4" you want. For my part if the piece is long I prefer the free hand, out of the table for shorter pieces the table is the best for me. Either way be sure to go against the direction of rotation of the bit. In the table it feeds right to left, free hand left to right. If you feed with the direction of rotation the router will "take off" with you and can lead to an injury, it is called a "climb cut" and is sometimes nessary to use but only after much experience. If you use a router table be sure not to get your stock between the bit and the fence, once again a not good outcome.

It may be that you already know all this but when you asked about chamfer bit I suspected you all have had limited experience with a router. Some others may wish to add some from their experience. Just be sure to be safe and enjoy the experience.
__________________
Wisdom: Where experience and knowledge combine and become one.

"We are all one decision away from Stupid!!"

Lamentations 3:22-23

"How often we sacrifice the permanent plans of God on the altar of immediate solutions"

I have a very good memory, just short is all.
xplorx4 is offline
Old 11-13-2011, 02:45 PM   #4 (permalink)
Forum Liaison

Mike's Avatar

Join Date: Nov 2004
Country: United States
First Name: Mike
Posts: 10,581
Mike is a jewel in the rough

Send a message via Skype™ to Mike
Default
Report Post Report This Post!

The bearing bits are handy for putting a chamfer on the edge of a board but I think you are better off buying a large diameter V bit. This bit will also cut the chamfer but can be used for other operations as well. I got this bit years ago and find new uses for it all the time. I am going to buy a larger version and that is what I recommend you look for.
Attached Thumbnails
Can you cut 45 degree angles with a router bit?-quarter-storage02.jpg

__________________
Mike
"Living in the D" (this means Detroit!)
"It's fine to disagree with other members as long as you respect their opinions"
Mike is offline
Old 11-13-2011, 02:54 PM   #5 (permalink)
Forum Contributor

xplorx4's Avatar

Join Date: Dec 2008
Country: United States
First Name: Jerry
Posts: 10,646
xplorx4 will become famous soon enough

Default
Report Post Report This Post!

Mike is correct about the "V" bit just remember it must be used in the router table.
__________________
Wisdom: Where experience and knowledge combine and become one.

"We are all one decision away from Stupid!!"

Lamentations 3:22-23

"How often we sacrifice the permanent plans of God on the altar of immediate solutions"

I have a very good memory, just short is all.
xplorx4 is offline
Old 11-13-2011, 02:58 PM   #6 (permalink)
Forum Liaison

Mike's Avatar

Join Date: Nov 2004
Country: United States
First Name: Mike
Posts: 10,581
Mike is a jewel in the rough

Send a message via Skype™ to Mike
Default
Report Post Report This Post!

Jerry, you can use the V bit with an edge guide as well for free hand work.
__________________
Mike
"Living in the D" (this means Detroit!)
"It's fine to disagree with other members as long as you respect their opinions"
Mike is offline
Old 11-14-2011, 12:11 AM   #7 (permalink)
Registered User

daveinvegas's Avatar

Join Date: Nov 2011
Country: United States
First Name: N/a
Posts: 47
daveinvegas is on a distinguished road

Default
Report Post Report This Post!



A 45 degree router bit makes a nice 45 degree edge.

I did this one with a bit with a bearing and router table.
__________________
SIN CITY CUSTOM
Firearm repair, holsters, grips and displays
http://zenoproductsservices.weebly.com/index.html
daveinvegas is offline
Sponsored Advertisements. Register to disable this advertisement.

Advertisement

Old 11-14-2011, 02:39 AM   #8 (permalink)
Forum Contributor

xplorx4's Avatar

Join Date: Dec 2008
Country: United States
First Name: Jerry
Posts: 10,646
xplorx4 will become famous soon enough

Default
Report Post Report This Post!

Agreed, it just seemed these folks were not too experienced with their router so I thought the chamfer bit would be easier for them.
__________________
Wisdom: Where experience and knowledge combine and become one.

"We are all one decision away from Stupid!!"

Lamentations 3:22-23

"How often we sacrifice the permanent plans of God on the altar of immediate solutions"

I have a very good memory, just short is all.
xplorx4 is offline
Old 12-10-2011, 11:01 AM   #9 (permalink)
Registered User

Ken Bee's Avatar

Join Date: Dec 2010
Country: United States
First Name: Ken
Posts: 408
Ken Bee is on a distinguished road

Default
Report Post Report This Post!

I just bought a "V Bit" to cut 45 degree miter joints in a box carcase without breaking the grain pattern around the box sides. I still use the 45 degree chamfer bit with bearing when using different woods in my box carcase miter joints. I also discovered having different cutting depths are nice to have on hand.

Just my less than 2 cents worth of info.
__________________
When something is advertised as being foolproof there is always a better class of fool that comes along to prove them wrong.
Ken Bee is offline
Old 12-11-2011, 12:43 AM   #10 (permalink)
Forum Contributor

harrysin's Avatar

Join Date: Jan 2007
Country: Australia
First Name: Harry
Posts: 11,170
harrysin is a splendid one to beholdharrysin is a splendid one to beholdharrysin is a splendid one to behold

Send a message via Skype™ to harrysin
Default
Report Post Report This Post!

Quote:
Originally Posted by jchutch75 View Post
Hi from AZ. My husband, Paul, and I are attempting to build a bar. The project design said it is for novices, but I am not so sure. Can you cut 45 degree angles with a router bit? If so, what bit? We have to cut 45 degree angles into both sides of a 2 x 6. They are only 1/4 inch deep.
I do most of my 45° joints on the router table, as shown in many of my threads. These shots are taken from project that I did via email for a disabled member some time ago.
If routing narrow pieces it's essential to use a decent size right angled pusher.
Attached Thumbnails
Can you cut 45 degree angles with a router bit?-johns-box7.jpg

Can you cut 45 degree angles with a router bit?-johns-box8.jpg

Can you cut 45 degree angles with a router bit?-johns-box9.jpg
