post #1 of 9 (permalink) Old 05-11-2015, 05:51 PM Thread Starter
Registered User

Join Date: May 2015
Country: United States
First Name: Ken
Posts: 1

Default Router Lift Issues

New to the forum. Hoping someone can shed some light on an issue I'm running into with my router lift. I can set the height I need but once the router is on for a brief time the bit will drop or raise in height. Original lift was a Jet Xacta lift made by Jessum. Thought it was an issue with the lift itself so I purchased a new lift from Woodworkers Supply this weekend. Finished setup this afternoon and the problem is reoccurring with the new lift. Router motor is from a Porter Cable 690 with 1/2" collet. Issue happens with multiple bits. Almost seems as if the router spindle is out of tolerance. Any thoughts?
kbgoodex is offline
Sponsored Links
Advertisement

post #2 of 9 (permalink) Old 05-11-2015, 06:01 PM
Forum Contributor

Stick486's Avatar

Join Date: Jan 2013
Country: United States
First Name: Stick
Posts: 25,284

Default

Quote:
Originally Posted by kbgoodex View Post
New to the forum. Hoping someone can shed some light on an issue I'm running into with my router lift. I can set the height I need but once the router is on for a brief time the bit will drop or raise in height. Original lift was a Jet Xacta lift made by Jessum. Thought it was an issue with the lift itself so I purchased a new lift from Woodworkers Supply this weekend. Finished setup this afternoon and the problem is reoccurring with the new lift. Router motor is from a Porter Cable 690 with 1/2" collet. Issue happens with multiple bits. Almost seems as if the router spindle is out of tolerance. Any thoughts?
WTB it's the routers collet...
days end or just needs maint...
Attached Files
File Type: pdf Collet_Maintenance.pdf (86.2 KB, 73 views)
File Type: pdf Guide to Router Collets.pdf (163.0 KB, 63 views)
File Type: pdf STUCK ROUTER BITS.pdf (117.1 KB, 63 views)
timbertailor and billyjim like this.

This would have been the week that I'd have finished chewing thru the restraints...
If only new layers hadn't been added....

Stick....
Forget the primal scream, just ROAR!!!
"SNORK Mountain Congressional Library and Taxidermy”
Stick486 is online now
post #3 of 9 (permalink) Old 05-11-2015, 06:33 PM
Official Greeter

jw2170's Avatar

Join Date: Jan 2008
Country: Australia
First Name: James
Posts: 18,222

Send a message via Skype™ to jw2170
Default

Welcome to the forum, Ken.

James
Sydney, Australia
.

I don't mind if other members disagree with my comments.
I don't profess to know everything, and I may learn something new.

"Never attribute to malice that which is adequately explained by stupidity."




jw2170 is offline
Sponsored Links
Advertisement

post #4 of 9 (permalink) Old 05-11-2015, 08:35 PM
Moderation Team

Cherryville Chuck's Avatar

Join Date: Sep 2010
Country: Canada
First Name: Charles
Posts: 15,076

Default

Welcome Ken. I would have to agree with Stick. The most likely culprit is the collet.

Someone I consider a master woodworker once told me that a master woodworker is not someone who never makes mistakes. He is someone who is able to cover them up so that no one can tell.
Cherryville Chuck is online now
post #5 of 9 (permalink) Old 05-11-2015, 09:01 PM
Registered User

RainMan 2.0's Avatar

Join Date: May 2014
Country: Canada
First Name: Rick
Posts: 16,039

Default

Quote:
Originally Posted by Cherryville Chuck View Post
Welcome Ken. I would have to agree with Stick. The most likely culprit is the collet.
And Ken don't get Stick started on Porter Cables quality control
timbertailor and billyjim like this.

I don’t always insulate , but when I do .
Ok ,I never insulate
RainMan 2.0 is online now
post #6 of 9 (permalink) Old 05-12-2015, 07:17 AM
Forum Contributor

DesertRatTom's Avatar

Join Date: Jul 2012
Country: United States
First Name: Tom
Posts: 16,323

Default

Try putting a small rubber grommet into the collet. About 1/8th thick. Then you can bottom out the bit on the grommet which may help. If that fails, replace the collet. If that fails, get a Bosch.
billyjim and Stick486 like this.
DesertRatTom is online now
post #7 of 9 (permalink) Old 05-12-2015, 07:44 AM
Registered User

normie2's Avatar

Join Date: Apr 2015
Country: United States
First Name: larry
Posts: 3

Default bit adjustment

Are your bit shafts clean? Also, what brand bits are you using.
normie2 is offline
post #8 of 9 (permalink) Old 05-12-2015, 11:10 AM
Registered User

GregLittleWoodworks's Avatar

Join Date: Dec 2014
Country: United States
First Name: Greg
Posts: 306

Default

Weccome to the forum ken
If it happens with multiple bits then it would appear to be the collet. I had a problem with a 1/2" roundover bit slipping in my Bosch 1617 but it didn't slip with any other bit. Replaced that bit and problem solved.
since then I have replaced my collet with a Musclechuck and it is even more convenient for bit changes and none have slipped.
RainMan 2.0 likes this.

“Each step of every Wood Art project I design and build is considered my masterpiece… because I want the finished product to reflect the quality and creativeness of my work. I study each piece to get ideas and details that will evolve in my future creations.
GregLittleWoodworks is offline
post #9 of 9 (permalink) Old 05-13-2015, 08:07 PM
Registered User

Join Date: Oct 2009
Country: United States
First Name: Brad
Posts: 1,036

Default



I am currently taking bets.
RainMan 2.0 likes this.


Just remember what my father always said, " Half the people in this world are below average!", and everything in life will make a hellova lot more sense.

Last edited by timbertailor; 05-13-2015 at 08:10 PM.
timbertailor is offline
